Model 800 Features
Standard Features
- Automatic Electronic Flow Control – Maintains A Constant Extraction Rate Even If The Filter Blocks
- Adjustable Airflow
- Clear And Informative Graphic Display
- Gas And Particle Sensors On The Exhaust
- Low Capital And Running Costs
- Quick Change Patented Labyrinth Pre-Filters Deliver Longer Filter Life
- Submicronic (HEPA) Filtration Removes 99.997% Of Particles Down To 0.3 Microns
- Activated Carbon Filtration Removes Harmful Gas
- Interface With Other Equipment; i.e. Lasers
- Simple To Install And Quiet In Operation
- Easy To Relocate And Precision Made From Stainless Steel
- High Performance Brushless Motors
Technical Specifications
Model 800 Specifications
| Voltage | 120v | 230v |
| Wattage | 2.4kW | 2.4kW |
| Frequency | 50Hz / 60Hz | 50Hz / 60Hz |
| Cabinet Height (Includes Castors) | 29.1 in (740mm) | 29.1 in (740mm) |
| Cabinet Width | 22.48 in (571mm) | 22.48 in (571mm) |
| Cabinet Depth | 26.5 in (675mm) | 26.5 in (675mm) |
| Cabinet Weight | 171.9 lbs (78kg) | 171.9 lbs (78kg) |
| Sound Level | <60dBa | <60dBa |
| Airflow | 800m3/h | 800m3/h |
Included Filter Specifications
| Main Filter | HEPA/Chemical |
| Pre-filter | F5 Pad |
Model 800i Features
Standard Features
- Automatic Electronic Flow Control – Maintains A Constant Extraction Rate Even If The Filter Blocks
- Adjustable Airflow
- Clear And Informative Graphic Display
- Gas And Particle Sensors On The Exhaust
- Low Capital And Running Costs
- Quick Change Patented Labyrinth Pre-Filters Deliver Longer Filter Life
- Submicronic (HEPA) Filtration Removes 99.997% Of Particles Down To 0.3 Microns
- Activated Carbon Filtration removes Harmful Gas
- Interface With Other Equipment; i.e. Lasers
- Simple To Install And Quiet In Operation
- Easy To Relocate And Precision Made From Stainless Steel
- High Performance Brushless Motors
- *800I 3T Used For Heavy Acrylic Use
Technical Specifications
Model 800i Specifications
| Voltage | 120v | 230v |
| Wattage | 2.4kW | 2.4kW |
| Frequency | 50Hz / 60Hz | 50Hz / 60Hz |
| Cabinet Height (Includes Castors) | 45.47 in (1155mm) | 45.47 in (1155mm) |
| Cabinet Width | 22.48 in (571mm) | 22.48 in (571mm) |
| Cabinet Depth | 26.5 in (675mm) | 26.5 in (675mm) |
| Cabinet Weight | 183lbs (83kg) | 183lbs (83kg) |
| Sound Level | <60dBa | <60dBa |
| Airflow | 800m3/h | 800m3/h |
Included Filter Specifications
| Main Filter | HEPA/Chemical |
| Pre-filter | F5 Pad |
